The Sound Town ZETHUS Series ZETHUS-M3X4 line array system includes:
- (2) ZETHUS-M3 6 x 3“ Line Array Passive PA Speakers (each ZETHUS-M3 contains a pair)
- (1) ZETHUS-M3FF Flying Frame
The line array PA speaker packs amazing sound and ample power handling into an ultra-compact cabinet. Weighing less than 20 lbs each, these speakers provide absolutely stunning sound in a small footprint. These speakers’ drivers are customized to generate impressive, high-efficiency sound reproduction. Each speaker handles 300W RMS, 600W peak power at 8-ohm.
These 4 line array speakers can be quickly stacked and secured with safety handles and quick-release pins. The angle between adjacent speakers can be adjusted from 0° to 8° to optimize coverage to the audience area. A heavy-duty flying frame is included in the package. Sound Town selects top-quality plywood for ZETHUS series speakers to ensure you can expect stellar sound quality across every detail and reliable protection for your PA rigs. Its rugged construction with heavy-duty perforated metal grille holds up to even the most demanding touring applications. This line array system provides the superior sound that seasoned engineers and musicians demand at touring grade.
- This line array system includes four 6 x 3“ line array passive PA speakers and one flying frame. The line array PA speaker packs amazing sound and ample power handling into an ultra-compact cabinet. Weighing less than 20 lbs each, these speakers provide absolutely stunning sound in a remarkably small footprint
- These 4 line array speakers can be quickly stacked and secured with safety handles and pins. The angle between adjacent speakers can be adjusted from 0° to 8° to optimize coverage to the audience area. A heavy-duty flying frame is included in the package
- Each speaker comes with 6 x 3“ mid-low frequency drivers and 6 x 1” dome tweeters. Even better, with an innovative horn-free design cabinet, the line array speaker delivers outstanding sound in a wide dispersion angle without sacrificing sound pressure
- With heavy-duty metal grille and aluminum extrusion rigging hardware, the speaker is easy to install both indoors and outdoors. High-quality plywood construction damps out unwanted vibrations and provides great protection, holding up very well to the toughest mobile applications
- The line array system is ideal for small to medium-sized applications including clubs, bars, restaurants, churches, schools and more
Specifications
Model | ZETHUS-M3 |
Active / Passive | Passive |
Frequency Range | 105 Hz - 18 kHz |
Frequency Response | 110 Hz - 18 kHz |
Sensitivity | 98 dB |
SPL Max | 122 dB |
Dispersion | 120º x 15º (H x V) |
Configuration | Full-range line array |
Transducer | MF: 6 x 3" driver, HF: 6 x 1" dome tweeter |
Impedance | 8Ω |
Power Handling | 300W RMS / 600W Peak |
Enclosure Material | High-grade 100% birch plywood |
Mounting Hardware |
ZETHUS-M3FF (flying frame) or ZETHUS-M3AD (pole & adapter), compact line array hardware |
Finish | Texture coating |
Grill & Rigging Component | Steel with anti-corrosion coat |
Amplifier | -- |
Input | 4-Pin Speakon |
Output | 4-Pin Speakon |
Signal Processing | -- |
Control | -- |
Indicator | -- |
Voltage | -- |
Dimension & Weight (each)
Product Width (in.) | 8.8" | Package Width (in.) | 21.9" |
Product Height (in.) | 11.0" | Package Height (in.) | 14.4" |
Product Depth (in.) | 11.0" | Package Depth (in.) | 14.6" |
Product Weight (lb.) | 15.7 lbs | Package Weight (lb.) | 35.8 lbs |
Warranty/Certifications
Manufacturer Warranty | 1 Year |
