360W 6-Zone 70V/100V Commercial Power Amplifier with Bluetooth, Optical, Phantom Power, for Restaurants, Lounges, Bars, Pubs, Schools
The Sound Town STCA360-6Z is a 6-zone 19” rack mountable commercial power amplifier. It comes with 360W RMS output and can be split into 6 zones. Its integrated clipping limiter protects your speakers and amp from overheating. Better yet, it is capable of 70-volt, 100-volt, 8-ohm, and 4-ohm and is ideal for applications such as restaurants, bars, pubs, schools and warehouse. Designed for commercial and public address applications, this amplifier comes with DC 24V power input and allows you to connect a backup 24V battery in case of a power outage.
The multi-zone power amplifier comes with 2 sets of RCA inputs, 3 mic inputs, SD card and Bluetooth, USB, FM radio and RCA line output, 70V / 100V / 4~16-ohm red positive speaker output terminals and shared negative speaker output terminal. Its versatile input and output options allows you to easily set this up in a variety of multi-room applications. Each of the 3 mics input has echo control all 6 zones have separate volume knobs for easy adjustment. Even better, the three mic inputs are phantom powered and compatible with condenser microphones.
- 6-zone speaker outputs with individual control
- Three phantom-powered mic inputs make using condenser microphones convenient
- Versatile inputs with 2 sets of RCA inputs, 3 mic inputs with 1 priority mic input on the front , SD card, USB input, FM radio tuner and Bluetooth; each of the 3 mics has repeat, speed, echo control
- Built-in clipping limiter protects your speakers and amp from overheating
- Ideal for multi-room applications such as Restaurants, Lounges, Bars, Pubs, Schools and Warehouses
|MIC INPUT||3mV, 600 Ω|
||200mV, 10k Ω|
|FREQ. RANGE||50 Hz~20k Hz|
|DISTORTION||0.5% (1k Hz)|
|S/N RATIO AUX||88 dB|
|S/N RATIO MIC||116 dB|
Dimension & Weight
|Product Width (in.)||19.0"||Package Width (in.)||20.9"|
|Product Height (in.)||3.5"||Package Height (in.)||6.9"|
|Product Depth (in.)||15.3"||Package Depth (in.)||18.7"|
|Product Weight (lb.)||26.0 lbs||Package Weight (lb.)||32.8 lbs|
|Manufacturer Warranty||1 Year
"Can the amplifier support 8-Ohms on one channel and 70V on the rest?"
(Answer:) Distortion may occur when some source signals are too large for input. 70V and 8-Ohm can't be used at the same time. A 6-zone cannot pick up 8-Ohm. If you want to connect 8-Ohm, you can only connect the 4-16 Ohms terminal of the main output and you can't connect any other 70V terminals.
But if all the speakers are 70V, you can connect more than one. And at the same time it can be connected to the main output of 70V-100V and 6-zone. Each zone in the 6-zone can be up to about 60W. But the whole amplifier maximum is 360W, including the main output and 6-zone sum.
"What type of speakers can the 6-zone connect to?"
(Answer:) Speakers that do not have a transformer can't be connected to the 6-zone settings on the amp, it can only connect to the 4~16 ohm terminal and can only connect a certain amount depending on the impedance. If the impedance of one speaker is 8-ohm, 2 in parallel is 4-ohm, so the amp can only connect to two 8-ohm speakers. The 6-zone connection can only be connected to a high impedance speaker (with transformer). Connecting a low impedance speaker to a high output impedance amplifier causes impedance mismatching, resulting in amplifier malfunction or damage.
"Does it have the ability to connect an exterior medium such as a phone line or
IP phone, or similar to be able to dial into it and page via a communication medium while not being directly in the same building as the amplifier itself?"
(Answer:) No, the amp does not have IP communication.
"Can your amplifier work with multiple lines at different voltages at the same time; for example: 100V, 70V, 4 Ohms & 8 Ohms etc?"
(Answer:) Low impedance 4-16 Ohms can't work at the same time with 70V/100V.
"I see that the six zones are labeled 100 volt speakers. All of our horns and speakers are 70 volt, can we still use the six zones outputs?"
(Answer:) Yes, you can connect the zones to either 70V/100V. The 100V speaker zone output in the 6 zones is actually designed for 100V and you can connect 70V speakers (although many speakers do in fact have 70/100V input on option where you would choose the 100V for the 6 zones labeled for 100V). For the speakers that only have 70V option, when connected to the 100V zone, the sound will be lower even when you turn the knob all the way up. For example, the power output might be around 42W @70V as opposed to 60W @100V. However, if your set up just needs background music, then it should be loud enough.
