CARME-112WPW15SWPW | Powered PA Speaker & Subwoofer Combo Set with One 12” PA Speaker, One 15” Subwoofer, One Subwoofer Pole, White
- DESCRIPTION
- FEATURES
- SPECIFICATIONS
- DOWNLOADS
- REVIEWS
The Sound Town CARME Series CARME-112WPW15SWPW speaker set includes:
- (1) CARME-112WPW CARME Series 12" 2-Way Powered PA/DJ Monitor Speaker, White w/ Compression Driver
- (1) CARME-15SWPW CARME Series 1400W 15” Powered Subwoofer with DSP, LPF, Birch Plywood, White
- (1) STSD-M20W Subwoofer/Speaker Extender Pole, Fits M20 Threading, White
The CARME-112WPW is a 12” powered PA speaker that handles 300W continuous, 600W peak power. The CARME-15SWPW is a 15” powered PA subwoofer with a Class-D amplifier built in. It generates 1400W massive power and serves up solid and mighty bass reinforcement. The 20-inch long STSD-M20W pole allows you to mount the PA speaker on top of the subwoofer.
The PA speaker comes with a 1 3/8” titanium compression driver and generates clean audio and stellar quality. With a frequency range of 48 Hz to 20K, this full-range speaker ensures a wide and accurate sound. The onboard digital signal processor (DSP) provides excellent system optimization and EQ capabilities. Both the PA speaker and subwoofer are active and setting up a PA system has never been this easy.
The speaker combo is ideal for meeting rooms, courtyards, churches, restaurants, stages, weddings and any other small to medium venues. The 5/8” textured and white painted plywood is more than beautiful, it comes with heavy-duty metal grille and holds up to touring applications.
- ALL-IN-ONE SOLUTION: The combo set includes one CARME-112WPW 12” powered PA speaker, one CARME-15SWPW 15” powered subwoofer, one STSD-M20W subwoofer/speaker extender pole.
- VERSATILE APPLICATIONS: The speaker combo is ideal for meeting rooms, courtyards, churches, restaurants, stages, weddings and any other small to medium venues. Both the PA speaker and subwoofer are powered, and it makes the setup a breeze.
- OUSTANDING SOUND QUALITY: The 12” PA speaker with 1 3/8” titanium compression driver generates clean audio and stellar quality. With a frequency range of 48 Hz to 20K, this full-range speaker ensures a wide and accurate sound. The 15” subwoofer serves up solid and mighty bass reinforcement.
- ONBOARD DSP: The onboard digital signal processor (DSP) provides excellent system optimization and EQ capabilities.
- STURDY CONSTRUCTION W/ PORTABILITY: The white painted plywood is more than beautiful. It comes with heavy-duty metal grille and holds up to touring applications.
Specifications
Model | CARME-112WPW | CARME-15SWPW |
Active / Passive | Active | Active |
Frequency Range | 48 Hz - 20 kHz | 35 Hz - 180 kHz |
Frequency Response | 52 Hz - 20 kHz | 38 Hz - 180 Hz |
Sensitivity | 99 dB | 99 dB |
SPL Max | 126 dB | 126 dB |
Dispersion | 100º x 55º (H x V) | -- |
Configuration | 12" active multi-angle full-range loudspeaker |
15" active high-power subwoofer |
Transducer | LF: 1 x 12", HF: 1 x 1.4" diaphragm | LF: 1 x 15" |
Voice Coil | -- | 4.0" |
Magnet | -- | 120 oz |
Impedance | 8Ω | 8Ω |
Power Handling | 300 / 600W | 700W RMS / 1400W Peak |
Enclosure Material | High-grade 100% birch plywood | High-grade 100% birch plywood |
Mounting Hardware | M8 inserts / optional U bracket |
Stand mount on top |
Finish | Texture coating (RAL colors available) |
Texture coating |
Grill & Rigging Component | Steel with anti-corrosion coat |
Steel with anti-corrosion coat |
Amplifier | Class-D amplifier w/ DSP |
Class-D amplifier w/ DSP, LPF |
Input | XLR line in |
2 x XLR-1/4" combo |
Output | XLR line out |
2 x XLR line out |
Signal Processing | DSP: PRESETTING, EQ, CROSSOVER, LIMIT ETC | EQ Presets, POLARITY, CROSSOVER |
Control | Volume, DSP software, MODE selector |
Master volume, phase, outputs mode (full-range/high-pass), EQ presets |
Indicator | Power, limit | Power, signal, limit |
Voltage | 100V-240V (50-60 Hz) | 100V-240V (50-60 Hz) |
Crossover Parts# | -- | STPAS-G2DSP |
High Frequency Driver Parts# | STHF-4403T | -- |
Low Frequency Woofer Parts# | MLF-12 | STLF-15AS |
Dimension & Weight
Model |
CARME-112WPW |
CARME-15SWPW | STSD-M20W |
Product Width (in.) | 14.4" | 18.9" | ∅1.4" |
Product Height (in.) | 26.2" | 22.0" | 20.0" |
Product Depth (in.) | 14.4" | 20.9" | --" |
Product Weight (lb.) |
51.8 lbs |
74.7 lbs |
1.2 lbs |
Package Width (in.) | 17.3" | 23.8" | --" |
Package Height (in.) | 29.5" | 25.2" | --" |
Package Depth (in.) | 17.3" | 21.7" | --" |
Package Weight (lb.) |
55.1 lbs |
79.0 lbs |
1.3 lbs |
Warranty/Certifications
Manufacturer Warranty | 1 Year |
