ZETHUS-115SW110WX4
ZETHUS Series Line Array Speaker System with One 15-inch Line Array Subwoofer, Four Compact 1 X 10-inch Line Array Speakers, White
The Sound Town ZETHUS Series ZETHUS-115SW110WX4 line array speaker system includes 1 x ZETHUS-115SW passive line array speaker, 4 x ZETHUS-110W passive line array speakers, 1 x ZETHUS-115SFF flying frame and 1 x ZETHUS-110WAD fly bar. The ZETHUS-115SW comes with extraordinary 500W RMS, 1000W peak (4-ohm) power handling capability and delivers rich and solid low-frequency reinforcement, the ZETHUS-110W is a lightweight and compact passive line array speaker which delivers superior sound quality with one 10” woofers, one 1.75” titanium compression driver and 300W RMS, 600W peak (8-Ohm) power handling capability.
Four ZETHUS-110W line array speakers can be quickly stacked and mounted to the ZETHUS-115SW subwoofer with a fly bar (ZETHUS-110WAD fly bar included in the package) and secured with attached mounting points and heavy-duty metal handles on the rear panels. Altogether they deliver accurate and immersive sound performance at earth shaking volume. With the mounting frame, the speaker system can be flown for optimum coverage. The line array speaker system is ideal for a wide range of installation applications ranging from live entertainment, clubs to churches or other venues where a line array speaker system is desired.
Note: Most power amplifiers won’t work at 2-ohm. To power four ZETHUS-110W passive speakers, it’s recommended to use a 2-channel power amplifier.
- The ZETHUS-115SW is a 15” passive subwoofer with extraordinary 500W RMS, 1000W peak (4-ohm) power handling capability and delivers rich and solid low-frequency reinforcement
- The ZETHUS-110W is a lightweight and compact passive line array speaker which delivers superior sound quality with one 10” woofer, one 1.75” titanium compression driver and 300W RMS, 600W peak (8-Ohm) power handling capability
- Four ZETHUS-110W line array speakers can be quickly stacked and mounted to the ZETHUS-115SW subwoofer with a fly bar (included in the package) and secured with attached mounting points and heavy-duty metal handles on the rear panels. Altogether they deliver accurate and immersive sound performance at earth shaking volume
- With the mounting frame, the speaker system can be flown for optimum coverage. Ideal for a wide range of installation applications ranging from live entertainment, clubs to churches or other venues where a line array speaker system is desired
Specifications
ZETHUS-115SW
| Model | ZETHUS-115SW |
| Frequency Response | 38 Hz - 180 Hz |
| Sensitivity | 100 dB (Passive) |
| SPL Max | 128 dB |
| Dispersion | -- |
| Configuration | 15" passive line array subwoofer |
| Transducer | LF: 1 x 15" |
| Voice Coil | 4" |
| Magnet | 100 oz |
| Impedance | 4Ω Nominal |
| Power Handling | 500 / 1000W |
| Connectors | 2 x 4 Pin Speakon |
| Cabinet Construction | High-grade 100% birch plywood |
| Mounting | Integrated line array hardware |
| Finish | Texture coating (RAL colors available) |
| Grill & Rigging Component | Steel with anti-corrosion coat |
| Amplifier | -- |
| Input | -- |
| Output | -- |
| Control | -- |
| Indicator | -- |
| Voltage | -- |
Dimension & Weight
| Product Width (in.) | 26.4" |
| Product Height (in.) | 17.7" |
| Product Depth (in.) | 24.4" |
| Product Weight (lb.) | 88.2 lbs |
ZETHUS-110W
| Model | ZETHUS-110W |
| Frequency Response | 55 Hz - 20 kHz |
| Sensitivity | 101 dB (Passive) |
| SPL Max | 128 dB |
| Dispersion | 90º x 20º (H x V) |
| Configuration | 10" passive full-range line array loudspeaker |
| Transducer | LF: 1 x 10", HF: 1 x 2" diaphragm |
| Voice Coil | 2.5" |
| Magnet | 50 oz |
| Impedance | 8Ω Nominal |
| Power Handling | 300 / 600W |
| Connectors | 2 x 4 Pin Speakon |
| Cabinet Construction | High-grade 100% birch plywood |
| Mounting | Integrated line array hardware |
| Finish | Texture coating (RAL colors available) |
| Grill & Rigging Component | Steel with anti-corrosion coat |
| Amplifier | -- |
| Input | -- |
| Output | -- |
| Control | -- |
| Indicator | -- |
| Voltage | -- |
Dimension & Weight
| Product Width (in.) | 19.5" |
| Product Height (in.) | 11.8" |
| Product Depth (in.) | 15.2" |
| Product Weight (lb.) | 55.1 lbs |
Warranty/Certifications
| Manufacturer Warranty | 1 Year |
Package Contents
- (1) ZETHUS-115SW Passive Line Array Subwoofer
- (4) ZETHUS-110W Passive Line Array Speakers
- (1) ZETHUS-115SFF Mounting Frame
- (1) ZETHUS-110WAD Fly Bar
Shipping Dimensions & Weight
| Model | Shipping Width (in.) | Shipping Height (in.) | Shipping Depth (in.) | Shipping Weight (lb.) |
| (1) ZETHUS-115SW | 29.4" | 21.1" | 27.4" | 90.6 lbs |
| (4) ZETHUS-110W | 15.0" | 23.0" | 18.4" | 47.4 lbs |
| (1) ZETHUS-115SFF | 28.5" | 6.3" | 27.0" | 51.3 lbs |
| (1) ZETHUS-110WAD | 27.8" | 4.5" | 25.3" | 17.6 lbs |
