TRITON-A12BD | TRITON Series Professional 12-Channel Passive Audio Mixer with USB interface, Recording, EQ, Bluetooth, DSP and 48V Phantom
The Sound Town Triton-A12BD is a compact sound mixer which comes with an enormous amount of features. Built in with top-quality preamps, the mixer delivers massive, natural-sounding bass and smooth, crisp highs while it keeps distortion to the minimum. The +48V phantom power is compatible with condenser microphones.
The Triton-A12BD has 12 line inputs including 4 stereo inputs and 4 balanced MIC inputs. It features a 3-band equalizer on mono inputs for precise control of your sound. High-Pass Filter allows you to eliminate unwanted low-frequency noise, for a smoother, cleaner mix. The USB interface and built-in Bluetooth makes it a breeze to connect your USB flash drive or Bluetooth devices including cellphones, tablets, pc, laptops, etc. to mix and record music.
Important! This mixer can now support PC/MAC/laptops via the USB interface (starting 02.18.2021). The mixer is also passive (non-powered) and cannot power other speakers.
12-channel mixing console with four stereo channels and one separate tape channel; separate input JACK controls for mic and line inputs on all mono channels.
Versatile inputs include XLR, ¼” and RCA Jacks. Ultra-low noise and discreet mic preamplifiers on all microphone inputs.
Built-in USB sound card and audio interface to record and connect to MAC or PC and universal digital audio file compatibility. Can be used by beginners or studio/professional applications.
Built-in +48V phantom power compatible with condenser mics.
High-quality components and sturdy construction holds up to touring applications and ensures long life. Ideal for live sound, home studio and mobile DJ.
|Channels||12 standard inputs|
|Inputs - MIC/LINE||4 balanced MIC/LINE inputs
|Inputs - Mono||3-band equalizer for mono inputs|
|Inputs - Stereo||4 stereo inputs
|Indicators||High-precision LED level indicator|
|Features||Built-in professional DSP|
|Common Mode Rejection||-80 dBu|
|S/N Ratio||> -82 dB|
|Frequency Response||+/- 0.5 dB, 20 Hz - 20 kHz|
|THD||less than < 0.03% @ 1 kHz|
|Replacement Power Adapter||T12BDPA|
Dimension & Weight
|Product Width (in.)||10.6"||Package Width (in.)||13.8"|
|Product Height (in.)||1.9"||Package Height (in.)||3.1"|
|Product Depth (in.)||8.7"||Package Depth (in.)||10.4"|
|Product Weight (lb.)||4.0 lbs||Package Weight (lb.)||4.6 lbs|
|Manufacturer Warranty||1 Year|
