FSN041.00 | Original Lavoce 4" Full-Range Driver with Neodymium Magnet, Waterproof Cone and Steel Frame, 40W at 16Ω for PA/DJ Speakers
Sound Town
English
简体中文
Русский языкEnglishThe LAVOCE FSN041.00 is a 4" full-range driver designed for high-performance professional systems. Boasting Italian acoustic design, it handles 40W AES / 80W program power at 16Ω, delivering consistent output in high-SPL applications. It features a lightweight neodymium magnet and a 1" CCAW high-temperature voice coil for efficient performance and stable operation under load.
With a frequency response of 110 Hz - 18 kHz, the FSN041.00 produces incredibly clear and extended high-frequency output paired with a punchy, controlled mid-bass. It features a waterproof cone design for improved resistance in exposed environments, paired with a heavy-duty, resonance-free steel basket for structural stability. This premium driver is built for professional PA applications where output, durability, and consistency are essential.
Specifications
| Model | FSN041.00 |
| Nominal Impedance | 16Ω |
| Minimum Impedance | 13.9Ω |
| Program Power | 80W |
| AES Power Rating | 40W |
| Sensitivity | 91.5 dB |
| Frequency Range | 110-18000 Hz |
| Voice Coil Diameter | 25 mm (1 in) |
| Chassis Material | Steel |
| Magnet Material | Neodymium |
| Magnet Dimensions OD x ID x H |
65 x 32 x 4 mm (2.56 x 1.26 x 0.16 in) |
| Coil Material | Copper |
| Former Material | Polyimide |
| Cone Material | Water-resistant treated paper |
| Surround Material | Rubber |
| Xmax | 2.6 mm (0.1 in) |
| Xmech | 3.6 mm (0.14 in) |
| Gap Height | 4 mm (0.16 in) |
| Voice Coil Winding Height | 7.2 mm (0.28 in) |
| Driver Displacement Volume | 0.09 l (0.003 ft³) |
| Recommended Enclosure | 3.37 l (0.119 ft³) |
| Recommended Tuning | 110 Hz |
Dimension & Weight
| Product Width (in.) | Ø 4.17” | Package Width (in.) | 4.9” |
| Product Height (in.) | 4.17” | Package Height (in.) | 4.3“ |
| Product Depth (in.) | 2.01” | Package Depth (in.) | 2.4” |
| Product Weight (lb.) | 1 lbs | Package Weight (lb.) | 1.1 lbs |
Warranty/Certifications
| Manufacturer Warranty | 1 Year |
