FILA-210LMHX4F | Passive Line Array Speaker System with Four Dual 10" Line Array Speakers, One Power Amplifier, One Flying Frame, Black







- DESCRIPTION
- FEATURES
- SPECIFICATIONS
- DOWNLOADS
- REVIEWS
Experience professional-grade sound with the Sound Town MODE Audio FILA-210LMHX4F line array system, a complete solution for high-performance audio. This set includes:
- (4) FILA-210LMH Dual 10" 3-Way 3100W Full-Range Line Array Loudspeaker
- (1) XDi-3604 High Power Density Class-D 4-Channel PA/DJ Power Amplifier
- (1) FILA-FR2 Flying Frame
Each MODE Audio FILA-210LMH line array speaker delivers precise, high-output audio with dual 10" neodymium woofers, a 5.5" MF neodymium transducer with 3.5" voice coil, a 2" coaxial HF neodymium compression driver with 2" diaphragm, delivering 1550W RMS and 3100W program power. Its 3-way bi-amped design separates frequencies, enhancing clarity across the low, mid, and high ranges while minimizing distortion. Built with a Baltic birch plywood enclosure and finished with a durable polyurea coating, the FILA-210LMH minimizes distortion and unwanted vibrations, while its rugged perforated steel grille provides durability and protection during transport.
The MODE Audio XDi-3604 Class-D amplifier is designed to complement the FILA-210LMH speakers, delivering 3600W RMS per channel at 4Ω. Featuring Power Factor Correction (PFC), it ensures efficiency, reduces heat, and stabilizes output, making it ideal for demanding live sound applications. The amplifier’s stable, high-quality output guarantees that every performance will have reliable and clear audio.
For optimal versatility, the MODE Audio FILA-FR2 flying frame enables secure suspension and precise positioning of the FILA-210LMH speakers, ideal for permanent installations. Featuring three safety pins and shackles, this frame ensures reliable suspension, providing a weight capacity of up to 3 tons for ultimate stability.
- MODE AUDIO SERIES FILA-210LMHX4F LINE ARRAY SPEAKER SYSTEM: The FILA-210LMHX4F set includes (4) FILA-210LMH line array speakers, (1) XDi-3604 power amplifier, and (1) FILA-FR2 flying frame—offering a comprehensive all-in-one line array solution.
-
FILA-210LMH 3-WAY LINE ARRAY SPEAKERS: Each FILA-210LMH features dual 10" neodymium woofers, a 5.5" MF transducer with 3.5" voice coil, and a 2" coaxial HF compression driver with a 2" diaphragm, delivering 1550W RMS and 3100W program power (LF: 1200W @ 8Ω, MF/HF: 350W @ 16Ω). 3-way bi-amped setup that separates low and mid/high frequencies, enabling precise frequency control and reducing distortion for various acoustic environments.
-
XDi-3604 PROFESSIONAL AMPLIFIER: The XDi-3604 is a class-D amplifier, delivering 3600W RMS per channel at 4Ω. With the Power Factor Correction (PFC) design, increases efficiency, reduces heat and interference while ensuring stable, high-quality output, Perfectly suited for use with FILA-210LMH line array speakers.
-
FILA-FR2 SUSPENSION FLYING FRAME: Achieve secure suspension for your FILA-210LMH line array speakers with the FILA-FR2 T-bar flying frame, enhancing audio performance in permanent installations or professional event setups. Featuring three safety pins and shackles, this frame ensures reliable suspension, providing a weight capacity of up to 3 tons for ultimate stability.
-
TOUR-LEVEL CRAFTSMANSHIP: Built with a premium Baltic birch plywood enclosure and finished with a durable polyurea coating, this design minimizes distortion and unwanted vibrations. A rugged perforated steel grille adds durability and protection, making it road-ready for reliable performance even in the most demanding conditions.
Specifications
Model | FILA-210LMH |
Active / Passive | Passive |
Frequency Range | 50 Hz - 20k Hz |
Frequency Response | 50 Hz - 20k Hz |
Sensitivity | 102 dB (Bi-amped LF) / 114 dB (Bi-amped MF/HF) |
SPL Max | 143 dB |
Dispersion | 120° Horizontal |
Configuration | High power dual 10" 3-way line array loudspeaker |
Transducer | LF: 2 x 10" ND woofer front loaded (4" VC) MF: 5.5" ND MF transducer HF: 2" ND coaxial compression driver |
Voice Coil | 4.0" |
Magnet | -- oz |
Impedance | LF=8Ω (LF wired individually) MF/HF=16Ω |
Power Handling | 1550W RMS, 3100W Program |
Enclosure Material | High-grade 100% birch plywood |
Mounting Hardware | Three points high temper aluminum rigging with easy setting locking mode configuration |
Finish | Textured black polyurea |
Grill & Rigging Component | Steel with anti-corrosion coat |
Amplifier | -- |
Input | 4-Pin Speakon |
Output | 4-Pin Speakon |
Signal Processing | -- |
Control | -- |
Indicator | -- |
Voltage | -- |
Crossover Parts# | -- |
High Frequency Driver Parts# | -- |
Low Frequency Woofer Parts# | -- |
Dimension & Weight
Model | FILA-210LMH | FILA-FR2 | XDi-3604 |
Product Width (in.) | 27.4" | 27.6" | 25.5" |
Product Height (in.) | 19.3" | 4.3" | 5.9" |
Product Depth (in.) | 10.9" | 23.9" | 25.5" |
Product Weight (lb.) | 64.2 lbs | 32.1 lbs | 35.0" |
Package Width (in.) | 31.4" | 30.5" | 18.9" |
Package Height (in.) | 23.2" | 6.3" | 1.7" |
Package Depth (in.) | 15.7" | 26.8" | 18.5" |
Package Weight (lb.) | 82.9 lbs | 34.1 lbs | 24.4 lbs |
Warranty/Certifications
Manufacturer Warranty | 1 Year |
