Introducing the Sound Town CARPO-K3WPW, a premium white colored column speaker from the CARPO series that is designed to enhance any audio setup. Equipped with dual 5-inch woofers and dual 3/4-inch compression drivers with linear horns, the CARPO-K3WPW delivers superior sound quality with a built-in class-D amplifier, capable of 250W continuous power and a peak power of 500W. Whether filling an auditorium or adding atmosphere to a lounge, the CARPO-K3WPW provides clear, powerful audio.
The CARPO-K3WPW enhances user control over audio output with adjustable bass and treble controls, allowing for a customized sound experience to match any environment. It also features flexible connectivity options, including a 1/4-inch & XLR combo input (mix/throughout switchable), a 1/8-inch AUX input, and True Wireless Stereo (TWS) Bluetooth with a signal indicator, complemented by an XLR output for seamless integration with other audio systems.
Designed for versatility, the CARPO-K3WPW speaker includes a wall-mount U-bracket and a 10-degree tilt adapter, along with a 35mm socket for easy tripod and speaker pole mounting. Optional accessories like the CARPO-WEP extension brackets to combine 2 CARPO-K3WPW speakers together and the CARPO-PFF flying frame offer additional setup configurations for more complex installation projects.
Constructed from robust birch plywood and finished with a durable white textured coating, the CARPO-K3WPW is built for both permanent installations and portable setups. This makes it an ideal choice for a multitude of settings, including stages, churches, restaurants, and outdoor spaces. Whether you are setting up for a concert or enhancing the ambiance of a dining area, the CARPO-K3WPW offers performance, versatility, and quality, making it a top choice for audio professionals and enthusiasts alike.
- CARPO SERIES CARPO-K3WPW COLUMN SPEAKER: The Sound Town CARPO-K3WPW white colored line array column speaker is engineered with dual 5“ woofers and dual 3/4” compression drivers with linear horns to ensure superb audio quality. It is equipped with a built-in class-D amplifier, capable of 250W continuous power and peak power of 500W
- ENHANCED AUDIO CONTROL: The CARPO-K3WPW features bass and treble controls, allowing users to customize and refine their audio experience to suit their preferences
- FLEXIBLE CONNECTIVITY OPTIONS: The CARPO-K3WPW speaker provides versatile connectivity, including a 1/4-inch & XLR combo input (mix/throughout switchable), a 1/8-inch AUX input, and True Wireless Stereo (TWS) Bluetooth connectivity with a signal indicator. Additionally, an XLR output enhances compatibility with a wide range of audio systems
- MOUNTING AND SETUP FLEXIBILITY: Included with the CARPO-K3WPW are a wall-mount U-bracket and an adapter for a 10-degree tilt adjustment (left-right, down). It also has a 35mm socket for easy mounting on tripods and speaker poles. Optional accessories such as the CARPO-WEP extension brackets to connect 2 CARPO-K3WPW speakers together and the CARPO-PFF flying frame for suspended setups are sold separately
- ROBUST BUILD & VERSATILE APPLICATIONS: Constructed from birch plywood with a durable white textured coating, the CARPO-K3WPW is designed for both permanent installations and portable setups. It is ideal for use in a variety of venues including auditoriums, stages, churches, restaurants, lounges, and outdoor spaces
Specifications
Model | CARPO-K3WPW, CARPO-K3PW |
Active / Passive | Active |
Frequency Range | 87Hz~20K Hz |
Frequency Response | 92Hz~20K Hz |
Sensitivity | 94dB, 1W @ 1 |
SPL Max | 124dB |
Dispersion | 120 x 20 Degrees |
Configuration | dual 5" woofers and dual 3/4" compression drivers |
Transducer | LF: 2 x 5", HF: 2 x 0.75" |
Voice Coil | 1.5" |
Magnet | 21 oz |
Impedance | 8Ω |
Power Handling | 250W RMS, 500W PROGRAM |
Enclosure Material | High-grade 100% birch plywood |
Mounting Hardware |
35mm mounting socket U-bracket (included) CWB-1A-PAIR Omnimount bracket (not included) CARPO-WEP extension bracket (not included) CARPO-PFF flying frame (not included) |
Finish | Texture coating |
Grill & Rigging Component | Steel with anti-corrosion coat |
Amplifier | AMP-150D-TWS |
Input | 2 x 1/4" & XLR COMBO (MIC/LINE) + 1 X 1/8" (AUX) / Bluetooth |
Output | XLR mixed out |
Signal Processing | BASS/TREBLE |
Control | -- |
Indicator | -- |
Voltage | 100V-240V (50-60 Hz) |
Crossover Parts# | -- |
High Frequency Driver Parts# | -- |
Low Frequency Woofer Parts# | -- |
Dimension & Weight
Product Width (in.) | 6.5" | Package Width (in.) | 11.4" |
Product Height (in.) | 21.3" | Package Height (in.) | 26.7" |
Product Depth (in.) | 8.5" | Package Depth (in.) | 9.4" |
Product Weight (lb.) | 21.5 lbs | Package Weight (lb.) | 27.1 lbs |
Warranty/Certifications
Manufacturer Warranty | 1 Year |
